Pipe bend Ø 104 x 2,00
Pipe bend Ø 104 x 2,00 | R 1.000 - 45° - leg 200/200 | HVA NIRO® 1.4301
Article Number
110419002
Pipe bend Ø 104 x 2,00 is available to buy in increments of 1
Availability
HVA NIRO
stainless steel pipe bend, outer diameter 104.0 x 2.0 mm
radius 1000 mm, 45°
with 200 mm leg extension each side
stainless steel tube welded, inner welding seam smoothed
material no. 1.4301 (AISI 304)
- highly wear-resistant -
stainless steel pipe bend, outer diameter 104.0 x 2.0 mm
radius 1000 mm, 45°
with 200 mm leg extension each side
stainless steel tube welded, inner welding seam smoothed
material no. 1.4301 (AISI 304)
- highly wear-resistant -
| Diameter | 104,00 mm |
|---|---|
| Wall thickness | 2,00 mm |
| Radius | 1.000,00 mm |
| Angle | 45,0 ° |
| Leg extension (short side) | 200,0 mm |
| Leg extension (long side) | 200,0 mm |
| Material | 1.4301 |
| Welding seam | laser welded, smothed |
| Norm | EN 10217-7 |
| Tolerance (norm) | ISO 1127 / D3-T3 |
| HVA-Niro® | yes |
Some downloads can only be viewed in logged-in state. If a desired download is not available, please feel free to contact us directly.
